CX系列
高溫高壓多級泵
高溫高壓多級泵
High-temperature high-pressure multistage pump
with cooling structure
with cooling structure
產品優勢/Product advantages
? 泵殼經水壓試驗，結構堅固，最高壓力可達30kg/cm2
The pump casing has been tested by water pressure, and its structure is solid, and the maximum pressure can reach 30kg/cm2? 泵葉輪經精密動平衡校正，轉動平穩，噪音小
The pump impeller is calibrated by precise dynamic balance, and it rotates smoothly with low noise? 水流道設計可靠，效率高，高溫下抗汽蝕性能優良
The pump flow passage is designed reliably, with high efficiency and excellent cavitation resistance at high temperature? 泵軸選用特種鋼材，抗氧化能力強，耐溫好，強度高，適合在高溫高轉速
The pump shaft is made of special steel with strong oxidation resistance, good temperature resistance and high strength, suitable for high temperature and high speed? 水泵采用機械密封，安全無泄漏，密封摩擦副材料為耐磨合金，使用壽命長
The pump adopts mechanical seal, which is safe and leak-free. The sealing friction pair material is wear-resistant alloy, with long service life? 備有水冷式設計，使用溫度高達200℃
With water-cooled design, the operating temperature can reach 200 ℃產品優勢/產品應用/Product application
CX系列高溫多級泵，適合不含固體顆粒之清水加壓、輸送、循環，如：
CX series high-temperature multistage pump is suitable for pressurizing, transporting and circulating clean water without solid particles, such as:? 鍋爐給水/Boiler feed wate
? 高溫高壓冷凝水回收/High temperature and high pressure condensate recovery
? 高樓供水/Water supply for high-rise buildings
性能參數/performance parameter
? 揚程/head：20-200m? 流量/flow：4-20m3/h
? 工作溫度/Temperature： ≤200℃
? 工作介質/Medium：清水/water
型號編碼/Model code
型號編碼/Model code
| 型號/Model | 流量 | 揚程/head m | 口徑Diameter | 電機/Motor380V50Hz | ||||
| flow | 工作揚程 | 最大揚程 | 入口 | 出口 | 型號 | 功率 | 轉速 | |
| (m3/h) | Use head | Max head | Inlet | Outlet | Model | Kw | rpm | |
| CX-1004 | 5.2 | 80 | 100 | DN40 | DN40 | 132S-2 | 5.5 | 2900rpm |
| CX-1005 | 100 | 130 | 132S-2 | 5.5 | ||||
| CX-1006 | 130 | 150 | 132S-2 | 7.5 | ||||
| CX-1007 | 150 | 180 | 132S-2 | 7.5 | ||||
| CX-1008 | 180 | 200 | 160M-2 | 11 | ||||
| CX-1504 | 8 | 80 | 100 | DN50 | DN50 | 132S-2 | 5.5 | 2900rpm |
| CX-1505 | 100 | 130 | 132S-2 | 7.5 | ||||
| CX-1506 | 130 | 150 | 160M-2 | 11 | ||||
| CX-1507 | 150 | 180 | 160M-2 | 11 | ||||
| CX-1508 | 180 | 200 | 160M-2 | 15 | ||||
| CX-2004 | 12 | 80 | 100 | DN50 | DN50 | 132S-2 | 7.5 | 2900rpm |
| CX-2005 | 100 | 130 | 160M-2 | 11 | ||||
| CX-2006 | 130 | 150 | 160M-2 | 15 | ||||
| CX-2007 | 150 | 180 | 160M-2 | 15 | ||||
| CX-2008 | 180 | 200 | 160L-2 | 18.5 | ||||
| CX-3005 | 18 | 80 | 100 | DN65 | DN50 | 160M-2 | 15 | 2900rpm |
| CX-3006 | 100 | 130 | 160L-2 | 18.5 | ||||
| CX-3007 | 130 | 150 | 180M-2 | 22 | ||||
| CX-3008 | 150 | 180 | 180M-2 | 22 | ||||
| CX-3009 | 180 | 200 | 200L1-2 | 30 | ||||
| CX-3010 | 180 | 200 | 200L1-2 | 30 | ||||
流量特性/Flow characteristics
